Fit is enough, less is more- Intel Alder Lake-N
platform in Mini-ITX Fanless Box PC.
Fit is enough, less is more- Intel Alder Lake-N platform in Mini-ITX Fanless Box PC
RSQ18 is integrated with a Mini-ITX motherboard.This compact and rugged embedded computer is convenient yet reliable for machine automation, industrial plants, kiosk control, and the IoT market.
| General | |
|---|---|
| CPU | Support Intel® Alder Lake N x7000 Series processors |
| Memory | DDR4 SO DIMM 8GB/16GB (optional) Mass Storage 1* SATA 3.0 1* M.2 (Key M type 2242/2280) for storage |
| Power Input | Standard: 9~24V DC input |
| Operation System | Windows® 11 Linux Ubuntu 20.04 |
| Basic I/O Interface | |
| Power Connector | DC24V input |
| Giga LAN | 2x GbE LAN |
| USB | 2x USB3.2 type A, 2x USB2.0 type A 1x USB type C (USB3.2/PD 20V 5A/DP) |
| Display | 2* HDMI, 1* USB-C(DP) |
| Expansion | 1x M.2 E Key 2230 for WIFI/BT, support Intel CNVi 1x M.2 B Key 3042/3052 & SIM Card Slot for 3G/4G/5G |
| Environmental | |
| Storage Temperature | -40°C ~ 85°C |
| Operating Temperature | 0°C ~ 50°C with airflow |
| Relative Humidity | 5 %~ 95 % (non-condensing) |
| Vibration | DIN Rail – 2G rms |
| Shock | Din-Rail – 15G half sign |
| Mechanical | |
| Dimension | 180mm (L) x 180mm (W) x 40 mm (H) |
| Net Weight | 1.54KG |
| EMC Standard | |
| EMC Standard | CE/FCC/UKCA Class A |
| Optional Accessories | |
| Power Adaptor | 60W/24V |
| Mounting Kit | Din Rail mount, Wall mount by project |
