Ultra-small form factor Mini-PC with Intel® ADL-N family processor
Fit is enough, less is more- Intel Alder Lake-N platform in tiny system
SQ11 is ultra-compact IPC implemented for industry fields. Slim and reliable system design supports the applications of edge computing and IIoT gateway. SQ11 also defined internal connector for rich I/O expansions, featuring wide-input power ranges.
| General | |
| CPU |
Intel® Atom™ ADL-N N100 processor |
| Memory |
DDR4 SO-DIMM: 8G/16G (option) |
| Mass Storage |
1x M.2 2280 PCIE x1/SATA SSD |
| Audio |
Codec: HDA SN6140 |
| Power Input |
DC Jack: 1x 2.5/5.5mm (12V) Standard: AC 100~240V |
| Operation System |
Windows® 11 IoT |
|
Wireless LAN |
802.11b/g/n/ac/ax and BT5.0 |
| Basic I/O Interface | |
| Giga LAN |
1x 2.5GLAN |
| USB |
2x USB Type-A 3.2 Gen2(Data) 2x USB Type-C full function (PD/DATA) PD3.0 |
| Display |
2x Standard HDMI2.0 4K60Hz 2x Full function Type-C |
| EMC Standard | |
|
EMC Standard |
CE/ UKCA/ FCC Class A |
| Environmental | |
| Storage Temperature |
-40℃~85℃ |
| Operating Temperature |
-20℃~50℃ with airflow |
| Relative Humidity |
5%~95%(non-condensing) |
| Vibration |
DIN Rail-1G rms |
| Shockn |
DIN Rail-15G half sign |
| Mechanical | |
| Dimension |
117mm(L) x 111mm (W) x 30mm(H) |
| Optional Accessories | |
| Power Adapter |
19V/2.1A, 40W max |
