Fit is enough, less is more- Intel Alder Lake-N platform in tiny system
WSB-AD00 is an industrial embedded computer with rich I/O, intelligent edge computing, high flexibility and easy PCIe expansion capabilities, featuringwide temperature ranges and structural strengthening, which is a perfect match with IoT platforms and scalable gateways.
| General | |
| CPU |
Support Intel® Atom® Alder Lake-N processors |
| Memory |
DDR4 SO DIMM 8GB/16GB (option) |
| Mass Storage |
1x M.2 (M Key, 2280, PCIe x2 NVMe/ SATA, SSD) |
| Power Input |
Standard: 12V |
| Operation System |
Windows® 10 IoT Enterprise Windows® 11 IoT Enterprise LTSC Linux |
| Basic I/O Interface | |
| Power Connector |
DC Jack (5.5×2.5mm) / DC 12V input |
| Giga LAN |
2x GbE LAN (Intel® i226-V) |
| USB |
3x USB3.0 type A, 2x USB2.0 type A |
| Display |
2x HDMI1.4, 1x DP1.4 |
| COM |
2x RS232 |
| Expansion |
1x M.2 E Key 2230 |
| Environmental | |
| Storage Temperature |
-40℃~80℃ |
| Operating Temperature |
0°C ~ 55°C with airflow |
| Relative Humidity |
5%~95%(non-condensing) |
| Vibration |
DIN Rail – 2G rms |
| Shock |
Din-Rail – 15G half sign |
| Mechanical | |
| Dimension |
163mm(L) x 125mm (W) x 53 mm(H) |
| Net Weight |
1.02KG |
| EMC Standard | |
| EMC Standard |
CE/FCC/UKCA Class A |
| Optional Accessories | |
| Power Adaptor |
12V/60W(option) |
| Mounting Kit |
Wall mount |
