帶 NUC主板 的無風扇嵌入式工業主機
微型 SQ11-NUC-J6412 尺寸僅為 110mm x 110mm x 40mm，並配備英特爾® Elkhart Lake 處理器。該系統具有兩個 DDR4 SODIMM 插槽，記憶體高達 32GB，一個由 PCIe 3.0 [x4] 驅動的 M.2 2280（M-Key）插槽，支持快速 NVMe SSD。
| Processor | Intel® Elkhart Lake SoC Processors |
| Memory | Two 260-pin DDR4 SODIMM sockets supported, up to 32G DDR4-3200 |
| Storage | 1 x m.2 (KEY M, 2242/2260/2280) with PCIe x1 and SATA3 for SSD |
| Graphic | Intel® Gen 11 Graphics |
| HDMI | 1 x HDMI port (HDMI2.0b) resolution up to 4096×2160@60Hz |
| Display Port | 1 x Display port (DP1.2++) resolution up to 4096×2160@60Hz |
| TPM2.0 | 1 |
| Watch-Dog Timer | 256 Segments, 0, 1, 2, …255sec |
| Ethernet | 2 x Realtek RTL8111G-CG/RTL8111H-CG with 10/100/1000 Mbps |
| USB | 2 x USB 3.2 Gen 2 (Type-A) 2 x USB 3.2 Gen 2 (Type-C) 2 x USB 2.0 (Type-A) |
| Audio | 1 x Combo Audio Jack (headphone & microphone jack) |
| Expansion | 1 x M.2 Key E 2230 (PCIex1, USB2.0) |
| OS | Win10 IoT & Linux |
| Power | 12V/90W |
| Dimension | L x W x H: 110 x 110 x 40 mm |
| Mounting | DIN-Rail or Wall-Mount |
| Environment | Operating temperature: 0 ~ 50°C |
| Certification | CE/FCC Class A |
