採用 Nano-ITX 的無風扇嵌入式工業主機
SQ13-NANO-6063 是一款微型、DIN 導軌安裝的嵌入式電腦。它由最新的 Intel Elkhart Lake CPU 提供支持，堅固耐用且功能強大，適合工業應用。它具有多種 I/O 端口，所有端口均位於易於連接和維護的位置。該系統還具有 M.2 2230（E-Key）插槽，支持 Wi-Fi 或藍牙連接。
| Processor | Intel® Elkhart Lake SoC Processors |
| Memory | One 260-pin DDR4 SODIMM socket supported, up to 32G DDR4-3200 |
| Storage | 1 x mini-PCIe socket support mSATA |
| Graphic | Intel® Gen 11 Graphics |
| HDMI | 1 x HDMI port (HDMI2.0b) resolution up to 4096×2160@60Hz |
| Display Port | 1 x Display port (DP1.2++) resolution up to 4096×2160@60Hz |
| TPM2.0 | 1 |
| Watch-Dog Timer | Programmable watchdog timer, time out period from 0.5 sec to 254.5 secs |
| Ethernet | 1x Intel® I210 GbE controller
1x GPY-215 controller |
| USB | 2 x USB 3.1 Gen 2 (Type-A) |
| Audio | 1 x Line Out |
| Expansion | 1 x M.2 Key E 2230 (PCIex1, USB2.0) |
| OS | Win10 IoT & Linux |
| Power | 12V/65W |
| Dimension | L x W x H: 132 x 132 x 44 mm |
| Mounting | DIN-Rail or Wall-Mount |
| Environment | Operating temperature: 0 ~ 50°C |
| Certification | CE/FCC Class A |
