DDR5

工業嵌入式記憶體

Features

JEDEC standard 1.1V Power Supply
Memory Organization: x8 FBGA DRAM chip
Average Refresh Period 7.8us at lower then TCASE 85°C, 3.9us at 85°C < TCASE < 95°C
Serial presence detect with EEPROM.
On Die Termination with ODT pin
RoHS Compliant

DDR5 DIMM 模組符合 JEDEC 標準。該模組採用高品質品牌DRAM芯片製造，並經過100%嚴格測試，具有更高的性能、更高的穩定性和更高的兼容性。

Model	UB-DIMM / SO-DIMM / ECC DIMM / R-DIMM
Interface	288pin / 262pin
NAND Flash Type	DDR5 4800 / 5200 / 5600 / 6000/ 64000 MT/s
Capacity	8GB / 16GB / 32GB
Sustained Read Performance(MB/sec)	Support ECC function
Sustained Write Performance(MB/sec)	38-38-38-70 / 40-40-40-80 / 42-42-42 90
Standard Operating Temperature (°C)	0°C~+85°C / -40°C~+85°C
Operating Voltage	1.1V
