15″ 電阻式觸控螢幕
15″ 電阻式觸控螢幕
工控等級面板, 1024×768 解析度, 廣溫液晶製程, 耐受溫度-30~70 度, 金屬外殼，搭配多樣化的安裝支架選項
| Panel Process | IAV Mode, Normally Black |
| Display Size | 15 inch |
| Visible Area | 304.1×228.1 mm |
| Resolution | 1024×768 (XGA) |
| Display Ratio | 4:3 |
| Color Depth | 1.67M Colors |
| Brightness(nits) | 500 / (optional) 1000 / (optional) 1500 nits |
| Contrast Ratio | 1000:1 |
| Pixel Pitch | 0.297×0.297 mm |
| Response Time | 25 msec. |
| Viewing Angle | 176″/176″ |
| Backlight | LED(white LED) |
| Backlight Lifetime | >70000 HRS |
| Operating Temp. | -30~70°C |
| Touch Technologh | Resistive Touch |
| Allowed Touch Points | Single point |
| Interface | USB/RS232 |
| Hardness | ≧3H |
| Dimension | 333x260x48(±2)mm |
| Weight | ≦5.0 KG |
